Efficiency

  • Up to 4.07 UEF reduces operating cost
  • ENERGY STAR® rated
  • Title 24 Compliant (JA13 Ready)

Performance

  • Delivers hot water faster than most standard electric water heaters
  • Ambient operating range: 37-145° F is widest in class, offering more days of HP operation annually; designed to meet Northern Climate Spec (Tier 4)

Easy Installation

  • Easy access side connections
  • Quick access to electrical junction box
  • Easily replaces a standard electric water heater

Integration

  • LED Screen with built-in water sensor alert with audible alarm1
  • Integrated EcoNet® Wi-Fi-connected2 technology and free mobile app gives users control over water heater, allowing for customizable temperature, vacation settings, energy savings and system monitoring at home or away
  • Demand Response Ready with built-in EcoPort (CTA-2045 Port)

 Integrated LeakGuard™ and LeakSense™ leak detection and prevention system

  • with factory installed auto water shut off valve limits leaks to no more than 20 ounces of water1, 3

Operation Modes

  • Energy Saver
  • Heat Pump
  • High Demand
  • Electric
  • Vacation/Away: 2-28 days (or placed on hold indefinitely)

Plus…

  • Premium grade anode rod with resistor extends the life of the tank
  • 3/4" NPT water inlet and outlet; 3/4" condensate drain connections
  • Incoloy stainless steel resistor elements
  • Dry-fire protection
  • Easy access, top mounted washable air filter
  • 2" Non-CFC foam insulation
  • Enhanced flow brass drain valve
  • Temperature and pressure relief valve installed • Design certified to NSF/ANSI 372 (Lead Content)

Warranty

  • 10-Year limited tank and parts warranty See Residential Warranty Certificate for complete information

Specifications

  • Up to a 4.07 UEF, Saves up to $576/ year
  • Universal Side and New Top Water Connections
  • New Duct Ready Design
  • Built-in LeakGaurd™ leak detection and prevention

Energy Guide Details

Certifications

  • C UL US
  • UL Listed C-US Classified
  • Energy Star
  • LEED Points = 3
  • AHRI B&W

Documents

Ultra Hybrid Electric Heat Pump with LeakGuard and Top Water Connections

Warranties

  • 10-Year limited tank and parts warranty
  • See Residential Warranty Certificate for complete information
